| Categories | DC Worm Gear Motor |
|---|---|
| Model Number: | FT-58SGM31ZY |
| Brand Name: | FUTENG |
| Place of Origin: | China |
| MOQ: | 1000 Pieces |
| Price: | Negotiable |
| Certification: | CE/ROHS/FCC/REACH/ISO14001/ ISO9001/ISO45001/IATF16949 |
| Packaging Details: | Standard Export Carton & Customzied |
| Delivery Time: | 15-30 days/Negotiable |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 8000 0000 |
| Continuous Current(A): | about 110mA-550mA |
| Efficiency: | 53% |
| Speed(RPM): | 2rpm-600rpm |
| Torque: | 1-100kgf.cm, 130/300/90/130(g.cm) |
| Type: | Gear Motor |
| Usage: | Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home |
| Geared motor model: | FT-58SGM31ZY |
| Gear box size: | 58*40.1mm |
| Voltage: | 1-24V |
| Speed: | 2rpm-600rpm |
| Rotating speed: | 5500/9000/3500/5500(rpm) |
| Rated voltage: | 12v/24v |
| Current: | 180/300/100/160(mA) |
| Output: | 5.5/21/2.5/5.6(w) |
| Name: | DC Worm Gear Motor |
| Company Info. |
| Dongguan Futeng Motor Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Gearbox Data: | ||||
Gear stages | 3 | 4 | ||
Reduction ratio (K) | 54,75,106 | 202,250,313,402,548,663,804,1327 | ||
Gear box length L(mm) | 31 | 19 | ||
Rated torque (kg·cm) | 7 | 0.5 | ||
Instant torque (kg·cm) | 12 | 1.5 | ||
Gearbox efficiency (%) | 53% | / | ||
Motor Data | ||||||||||||||||||
Motor Model | No Load | Load | Stall | |||||||||||||||
Motor Model | Rated Voltage | Speed | Current | Speed | Current | Output | Torque | Current | Torque | |||||||||
V | (rpm) | (mA) | (rpm) | (mA) | (w) | (g·cm) | (mA) | (g·cm) | ||||||||||
FT-31ZY | 12 | 5500 | 180 | 4100 | 750 | 5.5 | 130 | 3500 | 520 | |||||||||
FT-31ZY | 12 | 9000 | 300 | 6700 | 1500 | 21 | 300 | 6500 | 1200 | |||||||||
FT-31ZY | 24 | 3500 | 100 | 2600 | 220 | 2.5 | 90 | 850 | 360 | |||||||||
FT-31ZY | 24 | 5500 | 160 | 4100 | 320 | 5.6 | 130 | 1700 | 520 | |||||||||
|
