| Categories | Phoenix Contact Terminal Blocks |
|---|---|
| Brand Name: | Phoenix Contact |
| Model Number: | MSB 2,5 |
| Certification: | UL,CSA,EAC... |
| Place of Origin: | CN |
| MOQ: | 50 |
| Price: | $0.23-$0.3 |
| Payment Terms: | T/T |
| Supply Ability: | 800000 |
| Delivery Time: | 3-5work days |
| Packaging Details: | carton box |
| Product type: | Miniature terminal block |
| Number of connections: | 2 |
| Number of rows: | 1 |
| Rated surge voltage: | 8 kV |
| ominal current: | 24 A |
| similar requirements:: | 3248125 |
| voltage: | 800 V |
| Company Info. |
| Nanjing Dortmund Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Mini feed-through terminal block, nom. voltage: 800 V, nominal current: 24 A, number of connections: 2, connection method: Spring-cage connection, Rated cross section: 2.5 mm2, cross section: 0.08 mm2 - 4 mm2, mounting type: NS 15, color: gray
| Product type | Miniature terminal block |
| Number of connections | 2 |
| Number of rows | 1 |
| Potentials | 1 |
| Insulation characteristics | |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Rated surge voltage | 8 kV |
| Maximum power dissipation for nominal condition | 0.77 W |
| Number of connections per level | 2 |
| Nominal cross section | 2.5 mm² |
| Connection method | Spring-cage connection |
| Stripping length | 8 mm |
| Internal cylindrical gage | A3 |
| Connection in acc. with standard | IEC 60947-7-1 |
| Conductor cross-section rigid | 0.08 mm² ... 4 mm² |
| Cross section AWG | 28 ... 12 (converted acc. to IEC) |
| Conductor cross-section flexible | 0.08 mm² ... 2.5 mm² |
| Conductor cross-section, flexible [AWG] | 28 ... 14 (converted acc. to IEC) |
| Conductor cross-section flexible (ferrule without plastic sleeve) | 0.14 mm² ... 2.5 mm² |
| Flexible conductor cross-section (ferrule with plastic sleeve) | 0.14 mm² ... 2.5 mm² |
| 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve | 0.5 mm² |
| Nominal current | 24 A |
| Maximum load current | 30 A (with 4 mm² conductor cross-section) |
| Nominal voltage | 800 V |
| Nominal cross section | 2.5 mm² |
| Connection in acc. with standard | IEC/EN 60079-7 |
| Cross section AWG | 28 ... 12 (converted acc. to IEC) |
| Conductor cross-section, flexible [AWG] | 28 ... 14 (converted acc. to IEC) |
We can ship these goods to you by sea &air,DHL,UPS,FEDEX,TNT.......
FAQ
1. who are we?
We are based in NanJing City, JiangSu Province China, Start from 2018,sell to Mid East,Southeast Asia,North America,Domestic Market,South Asia,Eastern Asia,,Africa,. There are total about 11-50 people in our office.
2. how can we guarantee quality?
All of goods are from Original Brand New Phoenix Contact, and Provide Video-call, Picture confirmation before shipment. Always final Inspection before shipment;
3.what can you buy from us?
Terminal blocks/Relay/Power Supply....
4. why should you buy from us not from other suppliers?
Professional in instruments over 10 year. Covering many famous brands such as Phoenix Contact/Weidmuller/WAGO...... Cusutomers all over the world,south east of Asia,Middle East.....
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,CPT,Express Delivery； Accepted Payment Currency:USD,EUR,CNY; Accepted Payment Type: T/T,Credit Card,PayPal,
|
